Model:
BDA
Category:
Keywords:
E-mail:
Product
Main technical parameters
|
Model No. |
|
BDA series |
|
|
Rated capacity |
Q(kg) |
1000/1500/2000 |
|
|
Load center |
c(mm) |
500 |
|
|
Wheelbase |
Y(mm) |
1145 |
|
|
Service weight (with battery) |
kg |
265-350 |
|
|
Front wheel dimensions |
(mm) |
φ80x93 |
|
|
Rear wheel dimensions |
(mm) |
φ180x50 |
|
|
Lowered mast height |
h1(mm) |
2085/1835/2085/2335 |
|
|
Lifting height |
h3(mm) |
1600/2500/3000/3500 |
|
|
Fork lowered height |
h13(mm) |
90/75 |
|
|
Overall length |
l1(mm) |
1505 |
|
|
Overall width |
b1(mm) |
1050 |
|
|
Fork length |
l(mm) |
900/1070 |
|
|
Fork width |
b5(mm) |
680/980 |
|
|
Ground clearance |
m1(mm) |
28 |
|
|
Aisle width, pallet 1000x1200 (1200 crossways) |
Ast(mm) |
1705 |
|
|
Aisle width, pallet 800x1200 (1200 lengthways) |
Ast(mm) |
1755 |
|
|
Turning radius |
Wa(mm) |
1210 |
|
|
Lifting speed with / without load |
m/s |
135/150 |
|
|
Falling speed with / without load |
m/s |
Hand control |
|
|
Lifting motor power |
kW |
1.6 |
|
|
Battery voltage / rated capacity |
V/Ah |
12/(100/120/135) |
